Detection of sentinel and non-sentinel lymph node micrometastases by complete serial sectioning and immunohistochemical analysis for gastric cancer

Abstract

Background

We investigated the presence and distribution of the sentinel and the non-sentinel node micrometastases using complete serial sectioning and immunohistochemical staining (IHC), to inspect whether lymph node micrometastases spread to the sentinel lymph nodes first.

Methods

A total of 35 patients, who underwent gastrectomy with a sentinel lymph node biopsy for gastric cancer, were enrolled in this study. Total of 1028 lymph nodes of 35 patients having gastric cancer without metastasis of lymph node by permanent section with hematoxylin and eosin staining (H&E) were selected. There were 252 sentinel nodes and the other 776 were non-sentinel nodes. All nodes were sectioned serially and stained alternately with H&E and IHC. Lymph node micrometastases was defined as proving to be positive first either the IHC or the complete serial sectioning.

Results

Micrometastases were detected in 4 (11%) of the 35 patients, 6 (0.58%) of 1028 nodes. Of these 4 patients, 3 had micrometastases exclusively in sentinel nodes, and the other had micrometastasis in both sentinel and non-sentinel nodes. There was no patient who had the micrometasitases only in non-sentinel nodes.

Conclusion

These results support the concept that lymph node micrometastasis of gastric cancer spreads first to sentinel nodes.

Background

The prognosis of patients with gastric cancer is influenced primarily by the presence of lymph node metastases. Lymph node metastases in gastric cancer patients with submucosal invasion occur in 15 to 20% of patients; therefore, a lymph node dissection may be unnecessary for the remaining 80 to 85% of patients [1]. An accurate and reliable indicator to predict the absence of lymph node metastases would eliminate many unnecessary lymphadenectomies [1]. Therefore, a preoperative and accurate diagnosis of lymph node metastases remains important [24]. A sentinel node biopsy for gastric cancer is an intraoperative diagnostic method to detect lymph node metastases [57]. In 1992, Morton et al. [8] introduced the technique of intraoperative dye injection at the site of melanoma to identify the "sentinel" node, which is the first node that the afferent lymphatics enter from the tumor site. Miwa et al. [7, 9] employed this type of dye mapping technique to identify the sentinel nodes of gastric cancer, and reported a high positive predictive value and accuracy for the sentinel node biopsy of early gastric cancer. On the other hand, the presence of a micrometastasis in a lymph node is a serious issue for the clinical application of sentinel node biopsy for early gastric cancer. Lymph node micrometastases have been found in patients determined to be node-negative by routine histological examination. Previous investigators have reported that lymph node micrometastases could be detected using step sectioning, immunohistochemical staining and the reverse transcriptase-polymerase chain reaction [1012]. However, there have been a few reports about the distribution of micrometastases in both the sentinel and non-sentinel nodes in node-negative gastric cancer patients by routine histologic examination [1315].

In this study, we retrospectively investigated the presence and distribution of sentinel and non-sentinel node micrometastases using complete serial sectioning and immunohistochemical staining. These technique are the most accurate methods to detect micrometastases in nodes so that we could determine whether lymph node micrometastases had spread to the sentinel lymph nodes first.

Methods

A sentinel lymph node (SLNs) biopsy for gastric cancer was performed on 243 patients at the Department of Gastroenterologic Surgery, Kanazawa University Hospital from 1993 to 2002. Before the sentinel node biopsy was performed, written informed consent was obtained in accordance with the ethical standards of the Committee on Human Experimentation of Kanazawa University Hospital. Of these patients, we enrolled 35 who had a cancer that had invaded to the submucosa or muscularis propria and had no lymph node metastasis by routine histologic examination for this study. None of the patients had received preoperative chemotherapy or radiotherapy. Based on the Japanese Classification of Gastric Carcinoma, all 35 patients underwent a sentinel node biopsy followed by conventional lymphadenectomy for back-up dissection [16]. A total of 1028 lymph nodes were removed from the 35 patients. Of these, 252 lymph nodes were SLNs and the other 776 were non-SLNs. All 252 SLNs were negative for metastases both on intraoperative frozen-section examination and permanent section with hematoxylin and eosin staining (H&E). The other 776 nodes were negative for metastases on histological examination by H&E of multiple step sectioning at 0.2 cm intervals. The clinicopathologic data were evaluated according to the Japanese Classification of Gastric Cancer [16]. The patients characteristics are listed in Table 1. For detecting the SLNs, we used intraoperative endoscopic lymphatic mapping (IELM), which consisted of an intraoperative injection of 0.2 ml of 2% patent blue into the submucosal layer at four sites around the gastric carcinoma through a gastroscope [9]. The dye immediately appeared at the serosal surface and stained the lymphatic vessels and nodes [5, 9]. In this study, the SLN was defined as the lymph node that stained blue 20 minutes after the injection. The lymphatic basins were defined as the area containing the stained lymphatic vessels, and which were able to be divided into five categories according to the directions of the arteries surrounded the stomach, as follows: the left gastric artery area, the right gastric artery area, the right gastroepiploic artery area, the right gastroepiploic artery area and the posterior gastric artery area. The excised SLNs were sent for frozen-section examination. The lymph nodes stained with H&E on representative sections were cut along the plane with the largest diameter that included the node hilus, and examined intraoperatively for metastases.

Table 1 Patients characteristics

The remaining frozen tissues were thawed, and the tissues and non-SLNs were routinely cut at 0.2 cm intervals. Subsequently, the multiple sectioned lymph nodes and resected specimens were fixed in 10% formalin, processed through graded ethanol, and embedded in paraffin for permanent sections. The lymph nodes were stained with H&E and were examined by two pathologists.

In this study, all resected lymph nodes were sectioned serially at 25-μm intervals of 4-μm thickness in addition and either alternately stained with H&E and immunohistochemical staining (IHC) using an anti-cytokeratin antibody. The ENVISION technique was used (DAKO, Carpinteria, CA) for IHC and we used the monoclonal anti-human cytokeratin 8/18 antibody (Santa Cruz Biotechonology, California, USA) [1719]. All main tumor specimens from 35 patients were subjected to cytokeratin staining and were used as a positive control. A lymph node micrometastasis was defined as a node negative for metastasis by our routine histologic examination, but positive by either the IHC or the complete serial sectioning methods.

Results

The total number of sections examined was 24,094. Of these, 5986 were SLNs and 18,108 were non-SLNs. Of the 35 patients, 4 (11%) had micrometastases. A micrometastasis was found in 6 of 1028 nodes (0.6%) and 60 sections (0.3%) of 24,094 (Figs. 1, 2). Of these 6 nodes involving a micrometastasis, 4 were SLNs and the other 2 were non-SLNs in the lymphatic basin. No micrometastases were detected outside the basin (Table 2). The details of the distribution pattern, location and size of the micrometastases are shown in Tables 3, 4 and 5. Of the 4 patients who had a lymph node micrometastasis, 3 patients had micrometastases exclusively in the SLNs. The other patient had a micrometastasis in both the SLN and non-SLNs in the lymphatic basin. No patient had a micrometastasis only in non-SLNs. No patient has yet suffered a recurrence or has died as of December, 2007.

Table 2 Number and location of lymph nodes with micrometastasis
Table 3 Distribution pattern of lymph node micrometastasis
Table 4 Location of lymph node micrometastasis
Table 5 Site and size of lymph node micrometastasis
Figure 1
figure1

Lymph node mircrometastasis as detected by immunohistochemical staining with a cytokeratin antibody. (×400).

Figure 2
figure2

No cancer cells were identified in this section by routine histologic examination. (hematoxylin & eosin staining, ×40). (b) Lymph node micrometastasis in the representative section by the entire serial sectioning method. (Immunohistochemical staining, ×40). (c) Micrometastasis lymph node in the representative section by the entire serial sectioning method. (Immunohistochemical staining, ×400)

Discussion

Miwa et al. introduced the concept of sentinel node biopsy for gastric cancer [7]. The clinical use of the sentinel node biopsy to determine the surgical approach for gastric cancer requires the verification of this concept at the level of lymph node micrometastases. In this study, we investigated the presence and distribution of lymph node micrometastases in patients with gastric cancer who had a sentinel node biopsy. Recently, the presence of lymph node micrometastases undetectable by routine histological examination has been reported in breast, lung, esophagus, stomach, colon and gallbladder cancers. It has been reported that a lymph node micrometastasis was a poor prognostic indicator in breast, lung, and colon cancers [2022]. A few authors have reported that a lymph node micrometastasis was a poor prognostic factor in gastric cancer patients [23, 24]. Thus, the importance of the detecting a lymph node micrometastasis has been emphasized for various neoplastic diseases.

A variety of methods to detect lymph node micrometastases exist, including IHC and polymerase chain reaction assays. Matsumoto et al. demonstrated that the reverse transcriptase-polymerase chain reaction (RT-PCR) is more sensitive than IHC for the detection of micrometastases [2]. However, Yamamoto et al. [25] suggested that positive results with a molecular assay such as RT-PCR may not be indicative of the presence of viable tumor cells, but rather the presence of tumor DNA and thus, may be associated with a greatly increased false positive rate despite the higher sensitivity of the molecular assay. On the other hand, it has been reported that the serially sectioning increased the identification of tumor cells in the peripheral sinuses of lymph nodes [26]. It is thought that serial sectioning with IHC is the most accurate method for the detection of lymph node micrometastases. Therefore, we subjected the entire specimen to serial sectioning and IHC. The antibody used for IHC was a monoclonal anti-human cytokeratin 8/18 antibody which is more sensitive, specific, simple, accurate, and economic than other antibodies for IHC.

Tumor deposits within lymph nodes were classified and staged according to the revised guidelines set by the International Union Against Cancer (UICC) 6th Edition. According to this classification system, metastases less than 0.2 cm were considered micrometastases (MMs), and isolated tumor cells (ITCs) were single tumor cells or small clusters of cells that measured no greater than 0.2 mm and were usually detected by IHC or molecular methods, but may be verified with H&E. ITCs do not typically show evidence of metastatic activity by proliferation, induction of a stromal reaction, or penetration of vascular or lymphatic sinus wall invasion [27, 28]. Nakajo et al. [23] and Siewert et al. [29] reported that lymph node involvement is classified into cluster formation or single cell forms, according to the results of IHC for cytokeratin. Their results suggested that single cells cannot proliferate in lymph nodes because they were already killed by local and general immunocytes. A cluster of cells with a stromal reaction may easily proliferate and therefore have metastatic potential. In our department, resected lymph nodes are routinely cut at 0.2 cm intervals and the lymph nodes are examined for metastases. So, in this study, the definition of lymph node micrometastasis differed from the UICC classification. For this study it was defined as a node, negative for metastasis by our routine histological examination of sections cut at 0.2 cm intervals, but positive by complete serial sectioning with H&E and IHC. In addition, all single cell types and small cluster types without a stromal reaction by cytokeratin positive staining were not recognized as cancer cells in the next H&E stained slide. Thus, we excluded all single cells and small clusters without a stromal reaction, which are classified as ITCs in the UICC classification system, from the positive lymph node micrometastasis group [27, 28].

We excluded the gastric cancer patients whose tumors had invaded to the mucosa in this study because doing complete serial sectioning and immunohistochemical staining was a lot of work; in addition, the rate of a lymph node micrometastasis was low. Accordingly we enrolled 35 who had a gastric cancer that had invaded to the submucosa or muscularis propria and had no evidence of a lymph node metastasis by histologic examination for this study.

In this study, we observed a lymph node micrometastasis in 4 patients (11%) with a gastric cancer that had invaded to the submucosa or muscularis propria. In gastric cancer, Isozaki et al. [30] and Natsugoe et al. [31] reported that lymph node micrometastases were identified in 10 to 30% of specimens by step-sectioning or IHC. Our results were the most accurate of all the past studies and proved the actual circumstances of lymph node micrometastasis of gastric cancers that had invaded to the submucosa or muscularis propria.

In this study, we examined the lymph node micrometastases of SLNs and non-SLNs. We found lymph node micrometastases in the SLNs of 4 patients. One patient also had a micrometastasis in a non-SLN of the lymphatic basin, though no micrometastases of non-SLNs were identified outside the basin. Furthermore, no patient had a lymph node micrometastasis only in a non-SLN. Our results revealed that the patients who didn't have a lymph node micrometastasis in the SLNs also didn't have a micrometastasis in the non-SLNs. These results may support the concept that lymph node micrometastases spread first to the SLNs, then to the non-SLNs in the lymphatic basin and finally to non-SLNs outside the basin. Therefore, based upon this concept, it is sufficient to examine only the SLNs to determine whether or not there are lymph node micrometastases in patients with gastric cancer.

It is still unclear whether a lymph node micrometastasis is a prognostic factor in gastric cancer. However, a lymph node micrometastasis was found in gastric cancer patients who had no evidence of a lymph node metastasis by routine staining. This result suggests that we should cautiously reduce the extent of lymph node dissections. The intraoperative absence of a SLN micrometastasis suggests that the extent of lymph node dissection may be safely reduced, because it is unlikely for non-SLNs to have micrometastases without a SLN micrometastasis. In the case of breast cancer, the need for the intraoperative diagnosis of lymph node micrometastases is not essential, because additional dissection of the axillary lymph nodes can be performed easily. However, the subsequent dissection of lymph nodes is difficult in gastric cancer; therefore, the intraoperative diagnosis of lymph node micrometastases is crucial. We believed that when a lymph node micrometastasis was present, we should perform a lymph node dissection at the present. Our study utilized the most accurate methods, but we could not obtain the results rapidly enough for an itraoperative diagnosis. Therefore, we need to establish an accurate method for rapid intraoperative identification. Matsumoto et al. claimed that intraoperative rapid immunostaining was a simple and useful technique for detecting lymph node micrometastases [32]. An ultra-rapid RT-PCR system, which can complete the detection of cancer cells within approximately 70 minutes, has been developed. In the near future, these methods will be applied to detect lymph node micrometastases in SLNs during surgery [33].

Conclusion

we have demonstrated the ability to detect lymph node micrometastases by subjecting the entire specimen to complete serial sectioning and IHC for node-negative gastric cancer patients who have had a sentinel node biopsy. These results support the concept that lymph node micrometastases spreads first to the SLNs. In addition, the intraoperative and rapid diagnosis of lymph node micrometastases in SLNs may help guide the appropriate lymph node dissection in gastric cancer patients. Therefore, a rapid and accurate intraoperative diagnosis of lymph node micrometastases in SLNs will be necessary and should be the focus of future studies.

References

  1. 1.

    Higashi H, Natsugoe S, Ishigami S, et al: Distribution of lymph node metastasis including micrometastasis in gastric cancer with submucosal invasion. World J Surg. 2003, 27: 455-459. 10.1007/s00268-002-6601-4.

  2. 2.

    Matsumoto M, Natsugoe S, Ishigami S, et al: Lymph node micrometastasis and lymphatic mapping determined by reverse transcriptase-polymerase chain reaction in pN0 gastric carcinoma. Surgery. 2002, 131: 630-635. 10.1067/msy.2002.124632.

  3. 3.

    Morgagni P, Saragoni L, Folli S, et al: Lymph node micrometastases in patients with early gastric cancer: experience with 139 patients. Ann Surg Oncol. 2001, 8: 170-174. 10.1007/s10434-001-0170-x.

  4. 4.

    Morgagni P, Saragoni L, Scarpi E, et al: Lymph node micrometastases in early gastric cancer and their impact on prognosis. World J Surg. 2003, 27: 558-561. 10.1007/s00268-003-6797-y.

  5. 5.

    Hiratsuka M, Miyashiro I, Ishikawa O, et al: Application of sentinel node biopsy to gastric cancer surgery. Surgery. 2001, 129: 335-340. 10.1067/msy.2001.111699.

  6. 6.

    Kitagawa Y, Fujii H, Mukai M, Kubota T, Otani Y, Kitajima M: Radio-guided sentinel node detection for gastric cancer. Br J Surg. 2002, 89: 604-608. 10.1046/j.1365-2168.2002.02065.x.

  7. 7.

    Miwa K, Kinami S, Taniguchi K, Fushida S, Fujimura T, Nonomura A: Mapping sentinel nodes in patients with early-stage gastric carcinoma. Br J Surg. 2003, 90: 178-182. 10.1002/bjs.4031.

  8. 8.

    Morton DL, Wen DR, Wong JH, et al: Technical details of intraoperative lymphatic mapping for early stage melanoma. Arch Surg. 1992, 127: 392-399.

  9. 9.

    Miwa K: [Endoscopic lymphatic mapping: ELM]. Igaku no Ayumi. 1994, 11: 940-941. (in Japanese)

  10. 10.

    Ajisaka H, Miwa K: Micrometastases in sentinel nodes of gastric cancer. Br J Cancer. 2003, 89: 676-680. 10.1038/sj.bjc.6601183.

  11. 11.

    Veronesi U, Zurrida S, Mazzarol G, Viale G: Extensive frozen section examination of axillary sentinel nodes to determine selective axillary dissection. World J Surg. 2001, 25: 806-808. 10.1007/s00268-001-0009-4.

  12. 12.

    Viale G, Maiorano E, Mazzarol G, et al: Histologic detection and clinical implications of micrometastases in axillary sentinel lymph nodes for patients with breast carcinoma. Cancer. 2001, 92: 1378-1384. 10.1002/1097-0142(20010915)92:6<1378::AID-CNCR1460>3.0.CO;2-Y.

  13. 13.

    Arigami T, Natsugoe S, Uenosono Y, et al: Evaluation of sentinel node concept in gastric cancer based on lymph node micrometastasis determined by reverse transcription-polymerase chain reaction. Ann Surg. 2006, 243: 341-347. 10.1097/01.sla.0000201453.65534.f1.

  14. 14.

    Miyake K, Seshimo A, Kameoka S: Assessment of lymph node micrometastasis in early gastric cancer in relation to sentinel nodes. Gastric Cancer. 2006, 9: 197-202. 10.1007/s10120-006-0378-3.

  15. 15.

    Osaka H, Yashiro M, Sawada T, Katsuragi K, Hirakawa K: Is a lymph node detected by the dye-guided method a true sentinel node in gastric cancer?. Clin Cancer Res. 2006, 10 (20): 6912-6918. 10.1158/1078-0432.CCR-04-0476.

  16. 16.

    Japanease Reseach Society for Gastric Cancer: Japanease Classification of Gastric Carcinoma. 1999, Kanehara, Tokyo

  17. 17.

    Cartun RW: Immunohistochemistry of infectious disease. J Histotechnology. 1995, 18: 195-202.

  18. 18.

    Sabatini E, Bisgaard K, Ascani S, et al: A new immunohistochemical method for diagnostics and research. Critical comparison with the APAAP, ChemMate™, CSA, LABC, and SABC techniques. J Clin pathol. 1998, 51: 506-511.

  19. 19.

    Sasaki M, Watanabe H, Jass JR, Ajioka Y, Kobayashi M, Hatakeyama K: Immunoperoxidase staining for cytokeratins 8 and 18 is very sensitive for detection of occult node metastasis of colorectal cancer: a comparison with genetic analysis of K-ras. Hepatology. 1998, 32 (3): 199-208.

  20. 20.

    Passlick B, Izbicki JR, Kubuschok B, et al: Immunohistochemical assessment of individual tumor cells in lymph nodes of patients with non-small-cell lung cancer. J Clin Oncol. 1994, 12: 1827-1832.

  21. 21.

    Sasaki M, Watanabe H, Jass JR, et al: Occult lymph node metastases detected by cytokeratin immunohistochemistry predict recurrence in "node-negative" colorectal cancer. J Gastroenterol. 1997, 32: 758-764.

  22. 22.

    Trojani M, de Mascarel I, Bonichon F, Coindre JM, Delsol G: Micrometastases to axillary lymph nodes from carcinoma of breast: detection by immunohistochemistry and prognostic significance. Br J Cancer. 1987, 55: 303-306.

  23. 23.

    Nakajo A, Natsugoe S, Ishigami S, et al: Detection and prediction of micrometastasis in the lymph nodes of patients with pN0 gastric cancer. Ann Surg Oncol. 2001, 8: 158-162. 10.1007/s10434-001-0158-6.

  24. 24.

    Ishigami S, Natsugoe S, Tokuda K, et al: Clinical impact of micrometastasis of the lymph node in gastric cancer. Am Surg. 2002, 69: 573-577.

  25. 25.

    Yamamoto N, Kato Y, Yanagisawa A, Ohta H, Takahashi T, Kitagawa T: Predictive value of genetic diagnosis for cancer micrometastasis: histologic and experimental appraisal. Cancer. 1997, 80: 1393-1398. 10.1002/(SICI)1097-0142(19971015)80:8<1393::AID-CNCR5>3.0.CO;2-G.

  26. 26.

    Liu LH, Siziopikou KP, Gabram S, McClatchey KD: Evaluation of axillary sentinel lymph node biopsy by immunohistochemistry and multilevel sectioning in patients with breast carcinoma. Arch Pathol Lab Med. 2000, 124: 1670-1673.

  27. 27.

    Hermanek P, Hutter RV, Sobin LH, Wittekind C: International Union Against Cancer. Classification of isolated tumor cells and micrometastasis. Cancer. 1999, 86: 2668-2673. 10.1002/(SICI)1097-0142(19991215)86:12<2668::AID-CNCR11>3.0.CO;2-R.

  28. 28.

    Sobin LH, Wittekind CH: TNM Classification of Malignant Tumours. 2002, Willey, New York, 6

  29. 29.

    Siewert JR, Kestlmeier R, Busch R, et al: Benefits of D2 lymph node dissection for patients with gastric cancer and pN0 and pN1 lymph node metastases. Br J Surg. 1996, 83: 1144-1147. 10.1002/bjs.1800830836.

  30. 30.

    Isozaki H, Okajima K, Fujii K: Histological evaluation of lymph node metastasis on serial sectioning in gastric cancer with radical lymphadenectomy. Hepatogastroenterology. 1997, 44: 1133-1136.

  31. 31.

    Natsugoe S, Mueller J, Stein HJ, Feith M, Hofler H, Siewert JP: Micrometastasis and tumor cell microinvolvement of lymph nodes from esophageal squamous cell carcinoma: frequency, associated tumor characteristics, and impact on prognosis. Cancer. 1998, 83: 858-866. 10.1002/(SICI)1097-0142(19980901)83:5<858::AID-CNCR9>3.0.CO;2-E.

  32. 32.

    Matsumoto M, Natsugoe S, Ishigami S, Uenosono Y, Takao S, Aikou T: Rapid immunohistochemical detection of lymph node micrometastasis during operation for upper gastrointestinal carcinoma. Br J Surg. 2003, 90: 563-566. 10.1002/bjs.4083.

  33. 33.

    Marutsuka T, Shimada S, Shiomori K, et al: Mechanisms of peritoneal metastasis after operation for non-serosa-invasive gastric carcinoma: an ultrarapid detection system for intraperitoneal free cancer cells and a prophylactic strategy for peritoneal metastasis. Clin Cancer Res. 2003, 9: 678-685.

Download references

Acknowledgements

The authors are grateful to Professor Tetsuo Ohta in Kanazawa University for this study. And we also thanks to pre-professor Koichi Miwa.
